YT-S55T — Outdoor Vertical 55" Single-Sided LCD Totem
The YT-S55T is a 55-inch vertical landscape outdoor LCD totem — the primary large-format outdoor passenger information unit in the EN 50121 Series. At 2500+ nits it is fully readable in direct sunlight. IP65 and IK08-rated enclosure handles rain, dust, impact and UV. Certified to EN 50121-4 for electromagnetic compatibility in railway environments. Operates from −30 °C to +60 °C, making it suited to full four-season outdoor operation in Northern Europe.
Best for
- Railway platforms and stations
- Rail trackside environments
- Transit passenger information
Not ideal for
- Non-railway environments
- Exposed outdoor without shelter
Lead time
4–6 weeks
EXW Tallinn · from order confirmation
Integration
Connects to the systems you already run
Technical specifications
- Model
- YT-S55T
- LCD Panel
- LG 55" LED backlight, FullHD 1920×1080
- Brightness
- 2500+ nits
- Contrast Ratio
- min. 5000:1
- Viewing Angle
- 178° × 178°
- Response Time
- 6 ms
- Orientation
- Vertical (portrait) totem
- Operating Temperature
- −30 °C to +60 °C
- IP Rating
- IP65
- Impact Protection
- IK08
- Network
- Ethernet, Wi-Fi, 4G
- Interface
- AmpronLED CMS + REST HTTP
- Power
- 240 V AC, 700 W typical
- Case
- 1.2 mm galvanized plate, powder coated
- Front Panel
- Tempered glass AR OptiView laminate
- Operation
- 24/7
Annual operating cost (24/7)
Based on 700 W typical power draw. Edit the tariff to match your contract — the math updates live. Actual consumption varies with content brightness.
Features
- EN 50121-4 certified — electromagnetic compatibility for trackside use
- 2500+ nit brightness — fully readable in direct outdoor daylight
- Vertical totem format — maximises information display height at compact footprint
- IP65 and IK08 rated — sealed enclosure with impact resistance
- −30 °C to +60 °C operating range — full Nordic four-season operation
- AmpronLED content management via Ethernet, Wi-Fi or 4G
- Custom design available — contact for bespoke enclosure requirements
Ask about this product
A specific question about specs, sizing or integration? We'll reply within 24 hours.
Integrator network
Need someone to install it and connect it to your systems?
Most Ampron deployments are delivered by partner integrators across Europe — they handle on-site installation, system integration with your existing infrastructure, and long-term support. Tell us your location and project type and we'll connect you with the right team.
Applications
Model range
Other sizes in this series
Railway LCD
YT-S55W Indoor 55"
55-inch indoor LCD for platform concourses, waiting rooms and transit terminals.
Railway LCD
YT-S49W Outdoor 49"
49-inch weatherproof outdoor LCD for platform and trackside passenger information.
Railway LCD
YT Dual-Sided 49"
Dual-sided 49-inch outdoor LCD — visible from both platform sides for pole and overhead mounting.
Railway LCD
LCD Video Wall 1.6 mm
Multi-panel LCD video wall with 1.6 mm bezel gap for control rooms and operations centres.
Live deployments
This product in the field
Estonian Railway · Estonia
Real-Time Passenger Information Displays for Estonian Railway
Real-time passenger information displays for Estonian railway stations, integrated with train timetable and delay data.
Read case study →
Team LT UAB / Lithuanian Railways (LTG) · Lithuania
EN 50121-Certified LCD Displays for Lithuanian Railways
Over 200 EN 50121-certified LCD passenger information displays delivered to Lithuanian Railways — covering outdoor platforms, underground passages, indoor concourses and control room video walls across the national network.
Read case study →Deployed at 2 sites in 2 countries since Infinity.
Specify this product for your project.
Contact us with installation location, display distance and required integration.
