Compact LED
DS-960x640 — Large Compact LED Display
The DS-960x640 provides the highest information density in the DS range — 192×128 pixels at P5 pitch, in a 960×640 mm enclosure. This makes it the right choice for multi-line information boards: departure and arrival boards in transit hubs, warehouse status screens showing multiple process lines, gate assignment displays and facility overview panels. At 10 kg it mounts on standard overhead brackets. REST HTTP API. IP65 enclosure rated for outdoor and indoor installation.
Best for
- Compact multi-zone installations
- Bus stops and transit
- Indoor/outdoor status boards
- Production floor displays
Not ideal for
- Large-format outdoor advertising
- Single large-screen setups
Lead time
4–6 weeks
EXW Tallinn · from order confirmation
Integration
Connects to the systems you already run
Technical specifications
Specifications shown for P8 pixel pitch variant. P4 and P5 available on request.
- Model
- DS-960x640
- Pixel Pitch
- P5 standard (P4, P8 available)
- Resolution
- 192×128 pixels
- Brightness
- >5500 nits
- Dimensions
- 960×640×50 mm
- IP Rating
- IP65
- Operating Temperature
- −35 °C to +50 °C
- Input Voltage
- 240 V AC
- Power Avg
- 300 W
- Weight
- 10 kg
- Colour
- Full colour, 16 bit/colour
- Interface
- LAN + REST HTTP
- Operation
- 24/7
- Certification
- CE, RoHS
Annual operating cost (24/7)
Based on 300 W typical power draw. Edit the tariff to match your contract — the math updates live. Actual consumption varies with content brightness.
Features
- 880×600 mm active area — highest information density in the DS range at 192×128 pixels
- P5 pixel pitch standard — sharper text and graphics from 5 metres
- Available in P4 and P8 pixel pitch on request
- 10 kg — overhead bracket or wall mount; two-person installation recommended
- IP65 sealed enclosure — outdoor and indoor installation
- Multi-line display — departure boards, warehouse status, gate assignments
- REST HTTP API identical across all DS Series models
- Horizontal orientation standard; vertical on request
Ask about this product
A specific question about specs, sizing or integration? We'll reply within 24 hours.
Integrator network
Need someone to install it and connect it to your systems?
Most Ampron deployments are delivered by partner integrators across Europe — they handle on-site installation, system integration with your existing infrastructure, and long-term support. Tell us your location and project type and we'll connect you with the right team.
Applications
Model range
Other sizes in this series
Compact LED
DS-320x160
Smallest DS format — parking bay indicators, entry status and single-line guidance.
Compact LED
DS-640x160
Wide single-line format for aisle headers, direction arrows and zone labels.
Compact LED
DS-320x320
Square compact format for directional signs, lift lobbies and access control displays.
Compact LED
DS-640x320
The most widely deployed DS model — two-line text and graphic guidance.
Compact LED
DS-960x320
Wide two-zone compact board for split-message control and queue management.
Live deployments
This product in the field
Waybiller · Estonia
Real-Time Traffic Guidance at the Port of Kunda
Waybiller integrated Ampron's compact outdoor LED display at the Port of Kunda weighbridge — showing live weight, vehicle number and unloading instructions to truck drivers in real time.
Read case study →
Sheet metal manufacturer · Estonia
Truck Loading and Unloading Management LED Display System
LED message boards installed outside a sheet metal factory showing truck drivers their loading/unloading time slot and gate number — controlled automatically from the facility's truck management software.
Read case study →
Public transport operator · Estonia
Real-Time Bus Arrival API Integration into LED Message Boards
REST API integration connecting Ridango's transit management system to Ampron LED displays at bus stops — delivering real-time arrival data automatically.
Read case study →Deployed at 3 sites since Infinity.
Specify this product for your project.
Contact us with installation location, display distance and required integration.
